| Head material | YG8/K30 |
|---|---|
| Shank material | 40Cr, 45Cr |
| Packaging | 1pc/plastic box/inner box/carton |
| Surface | Can be coated with TiN, TiCN, TiALN, and LTE. |
| Testing issue | ISO Certification |
| No. | d(inch) | l (inch) | d1 (inch) | L (inch) | a |
|---|---|---|---|---|---|
| SL-42 | 1/8 | 1/2 | 1/8 | 1-1/2 | 14° |
| SL-1 | 1/4 | 5/8 | 1/4 | 1-15/16 | 14° |
| SL-2 | 5/16 | 1 | 1/4 | 2-13/16 | 14° |
| SL-3 | 3/8 | 1-1/8 | 1/4 | 3 | 14° |
| SL-4 | 1/2 | 1-1/8 | 1/4 | 3-1/16 | 14° |
| SL-6 | 5/8 | 1-5/16 | 1/4 | 3-1/4 | 14° |
| SL-7 | 3/4 | 1-1/2 | 1/4 | 3-7/16 | 14° |
| No. | d (mm) | I (mm) | d1 (mm) | L (mm) | a |
|---|---|---|---|---|---|
| L0313M03 | 3 | 13 | 3 | 50 | |
| L0413M04 | 4 | 13 | 4 | 50 | |
| L0616M06 | 6 | 16 | 6 | 56 | 14° |
| L0822M06 | 8 | 22 | 6 | 62 | 14° |
| L1025M06 | 10 | 25 | 6 | 65 | 14° |
| L1228M06 | 12 | 28 | 6 | 68 | 14° |
| L1430M06 | 14 | 30 | 6 | 70 | 14° |
| L1632M06 | 16 | 32 | 6 | 72 | 14° |
